EMI Test Receiver: R&S ESCI7 EMI Test Receiver: R&S ESCI7

The R&S®ESCI7 EMI test receiver is a standard compliant measuring receiver for EMC certification measurements in line eith commercial standards in the frequency range from 9 kHz to 7 GHz. The receiver conforms to the latest version of the CISPR 16-1-1 basic standard. At the same time, it functions as a full-featured and powerful spectrum analyzer for lab applications.

Miniature Filter Bank Module AM3023 Miniature Filter Bank Module AM3023

AM3023 is a miniature filter bank module with sub-octave filters covering the 100 MHz to 6000 MHz frequency range with a full 80-MHz overlap from 400 to 6000 MHz. The device contains a bypassable amplifier section and supports both transmit and receive applications.

Transmit/Receive Module for Phased Array Radar Transmit/Receive Module for Phased Array Radar

This rugged and liquid cooled transmit/receive module features high reliability, integral digital control and messaging, an integral power supply, low receiver noise figure, an integrated solid-state high-peak power pulsed amplifier, GaN-based power pallets, and more. It’s been designed to operate in an active phased array radar system and operates in the 2.9-3.3 GHz frequency range.

Weather Radar Product Solutions Weather Radar Product Solutions

Radar systems are critical for assisting meteorologists in weather forecasting by detecting changes in local weather patterns and bringing attention to distant weather patterns. CPI has the experience and range of products available to support new and existing weather radar systems.

L-Band Planar Array Antennas L-Band Planar Array Antennas

These transmit and receive L-band planar array antennas feature 14 dB gain, a wide bandwidth, linear polarization, and low return loss. They’re ideal for use in point-to-point applications, in RF transmitters and receivers, and in satellite communications.

Transmit/Receive Module for X-Band Phased Array Radar Transmit/Receive Module for X-Band Phased Array Radar

Aselsan’s AS-TRM-Z-10W is a compact and lightweight transmit/receive module that features power and temperature monitoring, a 50 Ohm input/output impedance, high reliability, ruggedness, bias sequencing, and fast TX/RX switching.

Transmit/Receive Module For Monopulse Radar Transmit/Receive Module For Monopulse Radar

The AS-TRM-Ku-10W is a compact and lightweight transmit/receive module that features high reliability, a rugged design, power and temperature monitoring, 50 Ohm input/output impedance, bias sequencing, fast TX/RX switching, and more. Each transmit chain and receive chains consist of a high-Q cavity bandpass filter, an LNA, and a limiter. This transmit/receive module is well suited for monopulse radar applications. For specifications and a mechanical outline, download the datasheet.

0.5 – 18 GHz High Performance Receiver: QR026 0.5 – 18 GHz High Performance Receiver: QR026

Teledyne’s QR026 is a high performance receiver designed to offer wide and synthesized capabilities from 500 MHz to 18 GHz, and frequency extensions up to 40 GHz. Its modular architecture allows it to be configured as a single, dual, triple, or quad channel unit, which can be used in many applications including electronic intelligence, electronic support measures, defensive aids suites, and combined ELINT/ESM sensors within ground, airborne, and naval environments.
