Microwave And RF Test Assemblies: GORE® PHASEFLEX® Series Microwave And RF Test Assemblies: GORE® PHASEFLEX® Series

The GORE® PHASEFLEX® Series offers the smallest, lightest, internally ruggedized microwave/RF test assemblies for high density interconnection in RF and uW modular applications as well as in high speed digital testing. These assemblies feature ON cable construction and provide consistent, repeatable measurements with electrical performance up to 18, 26.5, 40, or 50 GHz.

<B>Test And Measurement Cables</b> Test And Measurement Cables

MegaPhase has designed standard and unique high performance connectors and adapters. We offer a wide variety of standard connectors some of which include SMA, TNC, BNC, 2.4mm, 2.92mm, 3.5mm, 1.85mm, Type N and many more. In addition to the standard designs MegaPhase offers unique designs including our ZMA and ZN connectors for a quick disconnect bayonet style coupling these connectors offer RF keying if desired. We have designed standard straight and right angle adapters with in-series and between-series connectors. Applications include defense and commercial uses, and they are ideal for Probe Station Testing through 50 GHz. Our adapters feature linear phase slope, low SWR, and high reliability. When standard off the shelf RF connectors don’t meet your needs, our Engineering staff works with you to design interconnect products to meet your requirements, or re-engineer obsolete connectors. MegaPhase will provide excellent interconnect products that will allow you to focus on other aspects of your system design. The quality of these products is derived from our engineering staff’s years of experience in the design of custom connectors serving Defense, Commercial, and Aerospace Customers.

Field Mountable Microwave Cable: EACON Field Mountable Microwave Cable: EACON

To suit the needs of our customers, HUBER+SUHNER has developed this innovative solution. EACON stands for a simple, flexible and fast way to assemble microwave cables and connectors in the field without compromises to the best performance.

High Performance Interconnect Cable High Performance Interconnect Cable

The 9 series cable is a high performance interconnect cable for a wide range of applications including communications, radar, uplink/downlink, airborne and space. These assemblies feature a low loss triple shielded cable and give outstanding shielding effectiveness. They are available with various precision connectors which feature excellent VSWR.

Coaxial Cable Driver: CTS10EL89 Coaxial Cable Driver: CTS10EL89

The CTS10EL89 is a coaxial cable driver with internal input pull-down resistors and a 375ps propagation delay. It’s well suited for digital video applications as each of its outputs can be used as an independent driver.

Cable Assembly Solutions Cable Assembly Solutions

Fischer Connectors offers a large family of cable assembly solutions designed for a range of applications, including in extreme, medical, military, instrumentation, and fiber optic applications. Engineers are prepared to work closely with customers to find the ideal solution for the most demanding applications. Fischer Connector series include the Fischer Core Series, Fisher Ultimate™ Series, Fischer Fiberoptic series, and the Fischer Minimax™ Series.

Triple Shielded, Low Loss Cable Assemblies: NextPhase™ Series Triple Shielded, Low Loss Cable Assemblies: NextPhase™ Series

MegaPhase’s NextPhase™ Series is comprised of high performance interconnect cables that are designed to offer exceptional insertion loss performance at a reasonable cost. With operation from DC-40 GHz and availability in wide range of cable lengths, these assemblies are ideal for general purpose system interconnects.

General Purpose Bench Test Cable: RF Orange&trade; TM Series General Purpose Bench Test Cable: RF Orange™ TM Series

The TM series "RF Orange" cable is a cost effective solution for numerous production or general purpose test applications including ATE/ATS and BERT/scalar/spectrum. The GrooveTube® technology offers excellent phase and amplitude stability with flexure.
