Non-Blocking RF Switch Matrix Non-Blocking RF Switch Matrix

A non-blocking RF switch matrix is more complex than the blocking type, but it’s also more flexible. In this configuration, an input can be switched to multiple outputs. One input can in fact be switched to all of the outputs at once. This provides an extra degree of flexibility compared to the blocking architecture. However, a non-blocking architecture still has the limitation of not allowing two or more inputs to be switched to the same output. Input 1 for example can be simultaneously switched to every output or selectively switched to several outputs at once, but no other input can be switched to any of the same outputs.

64 x 64 L-Band Hurricane Matrix 64 x 64 L-Band Hurricane Matrix

ETL Systems presents the new 64 x 64 L-Band Hurricane Matrix customized to meet exact RX chain requirements for applications within the 850-2450 MHz frequency range. The unique design allows for the selection of input modules that exactly match teleport or broadcaster requirements. Each input port can be tailored with its own modules including fiber L-band input, LNB powering, variable gain / slope compensation, and RF level detection.

Reconfigurable CANBus Switch Matrix with Built-In Ethernet Port Reconfigurable CANBus Switch Matrix with Built-In Ethernet Port
Dow-Key Microwave provides a reconfigurable CANBus-based integrated switch matrix (P/N 13D12-480822T) equipped with a built-in ethernet port. This switch matrix is based on the well-established standard design of the SP12T switch with internal termination
Integrated Switch Matrices Integrated Switch Matrices

Ducommun RF Products has been actively working with our individual customers to develop unique testing solutions with our Switch Matrices and coaxial switches.  Ducommun RF Products has over twenty five years experience with the design and manufacturing of switch matrix systems.  Combining together our technical knowledge of both coaxial switches and switching systems, we have been able to assist our customers with a variety of solution that fit their unique requirements.  Ducommun RF Products offers a complete, fully supported, turnkey solution that allows our customers to have the benefit of a customized solution at a fraction of the price.

20 To 1100 MHz Fan-Out CANbus-Based Switch Matrix with Ethernet Interface 20 To 1100 MHz Fan-Out CANbus-Based Switch Matrix with Ethernet Interface
Dow-Key Microwave’s CANbus-based Switch Matrix System, with Ethernet control interface, performs from 20 to 1100 MHz and is available in full fan-out configurations from 8X8 to16X16
1U Electromechanical Switch Matrix with Ethernet, GPIB, RS-232, RS-485, and CANbus Interfaces 1U Electromechanical Switch Matrix with Ethernet, GPIB, RS-232, RS-485, and CANbus Interfaces
Dow-Key Microwave offers a CANbus-based Coaxial Switch Matrix system with Ethernet, GPIB, RS-232, RS-485, and CANbus control interfaces. This matrix performs up to 18 GHz and can be configured with up to four SP10T switch assemblies
Matrix Switch System Matrix Switch System
CrossPoint Technologie's MS-4001-32X32-HF-HIA is a Switch Matrix System covering the HF frequency band of 1.5 – 32 MHz. This system provides 32 X 32 non-blocking switching and distribution where any of the 32 inputs can be routed to one or all 32 outputs simultaneously...
Switch Matrix: R&S® ZN-Z84 Switch Matrix: R&S® ZN-Z84

The R&S® ZN-Z84 is a 48-port solution designed to complement the R&S ZNB network analyzer. It’s used to test multiport components for the wireless communications market in R&D and production phases. The matrix covers the 10 MHz to 8.5 GHz frequency range and can be controlled and operated directly from the ZNB network analyzer.
