Transceivers

Vector Signal Transceivers combine a vector signal generator and a vector signal analyzer with FPGA based real time signal processing and control. The NI PXIe-5644R RF Vector Signal Transceiver from National Instruments offers operation in the 65 MHz to 6 GHz frequency range, 80 MHz instantaneous bandwidth, and 24 channels of high speed digital I/O up to 250 Mbit/s. It’s used to test wireless and cellular standards.

This Frequency Modulated Continuous-Wave (FMCW) Radar transceiver is antenna mounted and operates at 76Ghz. This particular transceiver has been designed for high volume, low cost manufacturing. Because FMCW radars are short-range- this transceiver will most likely be used in commercial applications involving security, radar sensors for vehicles for backup aid or side object detection.

This UHF RF Data Transceiver operates in the 350 to 450 MHz frequency range, has a data rate up to 80 kbps, a 500 mA (@15.0 VDC) transmit current, a 135 mA (typical) receive current, -98 dBm (typical) sensitivity, an RF transmit power of 100 mW (typical), and more.  The RF-U-3545-TR-2 UHF RF Data Transceiver measures in at 9.10” x 3.26” x 0.57”. Custom designs changes in size, data rates, frequencies, modulations, RF power output, etc. are available.

Narda East’s SATCOM Transceivers & Up/Down Converters are small and light weight. The 80000 and 85000 series both feature low power consumption, and a high dynamic range receiver.

Anokiwave presents the AWMF-0108 highly integrated silicon quad core chip that is designed specifically for 5G phased array applications. This device functions within the 27.5 – 30 GHz frequency range, and operates in half duplex fashion, which enables a single antenna to support both Tx and Rx operation by supporting four Tx/Rx radiating elements.

This VHF Data Transceiver operates in the 46.00 to 47.00 MHz frequency range and has an RF output power of >100mW. However, its unique architecture allows the transceiver to be modified to support other frequency ranges and RF output power requirements.

The transceiver test system is the latest addition to JFW Industries' line of RF test systems. Its unique omni-directional design allows for complete interconnectivity and amplitude control, making it an ideal solution for transceiver testing.
