Adapters

RLC Electronics now offers Coaxial to Waveguide Adapters in a variety of configurations for your specific application. Option A are broadband adapters whose excellent electrical specs are maintained over the entire adapter bandwidth. While option B offers enhanced performance over a specific band of the adapters’ bandwidth...

SMA connectors, short for SubMiniature Version A, are semi-precision, subminiature devices that provide repeatable electrical performance from DC to 12.4 GHz with flexible cable. SMA connectors feature screw-type coupling. Semi-Rigid cabling extends the frequency range of the device to 18GHz. SMA connectors offer broadband performance with low reflections and constant 50 ohm impedance. These properties, along with minimum attenuation and low VSWR have made the SMA connector extremely popular in the microwave community. LTI SMA connectors are designed to conform to MIL-C-39012 specifications.

Krytar has just launched a new line of coaxial adapters that cover from DC to 40 GHz, depending on the model selected. The adapters come with SMA, 2.4, and 2.92 mm connector types

The universal cable kit contains the tools to properly terminate 3 different length cable sub-assemblies with various connector combinations as specified below. The brass, nickel plated adapters have gold plated center contacts and are housed in their own separate case. They can be easily removed with your fingertips in a work area or out in the field. The adapter kit and cables are then housed in a rugged sealed case.

Our available adapters feature rugged construction, quality RF performance, availability to be combined with any combination of SMA, N, or BNC connectors, and affordable customization.

MECA offers rugged and reliable between series adapters (bullets) and bulkhead adapters to provide simplified connectivity for your projects. Rugged jumper cables are also available, and come in the three of the most commonly used cable types (RG142, LMR240, LMR400). SMA, N, 7/16 DIN, BNC, and TNC connector style cables are available from stock. Several models from both products lines are available. The datasheet below contains information on their specifications, as well as links to individual model’s datasheets.

A line of N series coaxial adapters designed for the OEM market to test amplifier housings, broadband modems, headend equipment, and tuner modules

The Model AM Series consists of antenna mounting adapters that will allow polarization change during horizontal and vertical testing without removing the antenna from its tripod. The AM Series comes with a 20” non-metallic mast and is available for the earlier version antenna models listed below. Model Antenna AM1000 AT1000, AT1000A AM1001 AT1080, AT1080A AM6000 AT 5080, AT6080 NOTE: The AM series adapter comes standard on the AT1080B and AT6080A models.
