WR-15 High Directivity Waveguide Coupler, 20 dB, 50-75 GHz: C20-1500WG

Designed with a coupling factor of 20 dB, it operates effectively across a wide 50–75 GHz bandwidth, making it highly suitable for applications in advanced communications, radar, and test instrumentation. One of its key strengths is its impressive directivity of 41 dB, which ensures accurate signal sampling with minimal interference from the main transmission path.

Constructed with exceptional precision, the C20-1500WG is gold-plated to provide superior corrosion resistance, ensuring durability and long-term stability even in demanding environments. Its insertion loss is kept to a very low 0.9 dB, preserving signal integrity and minimizing system degradation. In addition, the component maintains an excellent return loss of 32 dB, contributing to overall system performance by minimizing reflected power and improving efficiency.

Manufactured to strict quality standards, the C20-1500WG is designed to meet the demanding requirements of modern RF and microwave systems. Its carefully controlled specifications enable it to deliver consistent performance while reducing negative impacts on the overall voltage standing wave ratio (VSWR) of the system. This makes it particularly valuable for high-frequency testing, signal routing, and monitoring applications where precision and reliability are paramount.

By combining wideband operation, high directivity, low loss, and robust construction, the C20-1500WG coupler stands out as a dependable solution for engineers seeking uncompromised performance in millimeter-wave transmission line components.
