PCB Design Considerations For High-Performance Filtering In mmWave Applications

RF circuits for applications in the mmWave range (30 to 300 GHz) require high-performance filtering to meet the high-data, high-speed functionality that operating at these higher frequencies promises. However, filters for devices operating in the mmWave range will not function optimally if your printed circuit board (PCB) is not configured appropriately. For this reason, RF design engineers need to make a number of critical PCB design decisions that range from selecting the right materials to developing a board configuration that will limit common issues such as spurious-wave-mode propagation, conductor and radiation losses, unwanted resonance, and dispersion.
