Passive MMIC DC-18 GHz Quadplexer: MMPX-00002PSM
Source: Marki Microwave
The MMPX-00002PSM is a MMIC surface mount quadplexer capable of multiplexing DC-6 GHz / 8-10 GHz / 12-14 GHz / 16-18 GHz signals.
Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MMPX-00002PSM is available as a 6x6mm QFN. Low unit to unit variation allows for accurate simulations using the provided SnP files taken from measured production units.
Features
- Excellent Return Loss
- 11 GHz crossover frequency
- High Band-Band Isolation
Applications
- Satellite Communications
- Reflectionless Filter Applications
- Electronic Warfare
