Passive GaAs MMIC Bandpass Filter: MFBP-xxxxxCH Series
Source: Marki Microwave
The passive MMIC bandpass filter die is an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions.
Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. These filters are available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.
Download the available datasheets or click here to learn more about the extended assortment.
| Product | Model Number |
| Passive GaAs MMIC 1.62 - 6.78 GHz Bandpass Filter | MFBP-00040CH |
| Passive GaAs MMIC 5.3 - 19.24 GHz Bandpass Filter | MFBP-00041CH |
| Passive GaAs MMIC 17.7 - 38.93 GHz Bandpass Filter | MFBP-00042CH |
| Passive GaAs MMIC 12.14 - 18.16 GHz Bandpass Filter | MFBP-00043CH |
| Passive GaAs MMIC 17.83 - 24.46 GHz Bandpass Filter | MFBP-00044CH |
| Passive GaAs MMIC 23.99 - 28.75 GHz Bandpass Filter | MFBP-00045CH |
| Passive GaAs MMIC 28.28 - 35.45 GHz Bandpass Filter | MFBP-00046CH |
| Passive GaAs MMIC 34.44 - 40.2 GHz Bandpass Filter | MFBP-00047CH |
| Passive GaAs MMIC 15.15 - 17.29 GHz Bandpass Filter | MFBP-00048CH |
| Passive GaAs MMIC 33.77 - 35.92 GHz Bandpass Filter | MFBP-00050CH |
| Passive GaAs MMIC 36.79 - 40 GHz Bandpass Filter | MFBP-00051CH |
| Passive GaAs MMIC 14.68 - 23.59 GHz Bandpass Filter | MFBP-00052CH |
| Passive GaAs MMIC 15.82 - 22.65 GHz Bandpass Filter | MFBP-00053CH |
| Passive GaAs MMIC 11.06 - 16.96 GHz Bandpass Filter | MFBP-00054CH |
| Passive GaAs MMIC 22.25 - 33.17 GHz Bandpass Filter | MFBP-00055CH |
| Passive GaAs MMIC 21.85 - 33.37 GHz Bandpass Filter | MFBP-00056CH |
| Passive GaAs MMIC 30.49 - 46.23 GHz Bandpass Filter | MFBP-00057CH |
| Passive GaAs MMIC 17.70 - 28.82 GHz Bandpass Filter | MFBP-00068CH |
| Passive GaAs MMIC 28.21 - 39.87 GHz Bandpass Filter | MFBP-00069CH |
| Passive GaAs MMIC 17.49 - 25.80 GHz Bandpass Filter | MFBP-00070CH |
| Passive GaAs MMIC 25.60 - 33.37 GHz Bandpass Filter | MFBP-00071CH |
| Passive GaAs MMIC 30.69 - 36.05 GHz Bandpass Filter | MFBP-00072CH |
| Passive GaAs MMIC 34.11- 37.26 GHz Bandpass Filter | MFBP-00073CH |
| Passive GaAs MMIC 36.39 - 39.80 GHz Bandpass Filter | MFBP-00075CH |
| Passive GaAs MMIC 8 - 10 GHz Bandpass Filter | MFBP-00079CH |
| Passive GaAs MMIC 10 - 12 GHz Bandpass Filter | MFBP-00080CH |
| Passive GaAs MMIC 12 - 14 GHz Bandpass Filter | MFBP-00081CH |
| Passive GaAs MMIC 14 - 16 GHz Bandpass Filter | MFBP-00082CH |
| Passive GaAs MMIC 16 - 18 GHz Bandpass Filter | MFBP-00083CH |
| Passive GaAs MMIC 6 - 9.1 GHz Bandpass Filter | MFBP-00084CH |
| Passive GaAs MMIC 8.8 - 14.4 GHz Bandpass Filter | MFBP-00085CH |
| Passive GaAs MMIC 12.5 - 17.5 GHz Bandpass Filter | MFBP-00086CH |
| Passive GaAs MMIC 29.75 - 39.75 GHz Bandpass Filter | MFBP-00087CH |
| Passive GaAs MMIC 18 - 27.5 GHz Bandpass Filter | MFBP-00089CH |
| Passive GaAs MMIC 21.53 - 29.82 GHz Bandpass Filter | MFBP-00100CH |
| Passive GaAs MMIC 27.56 - 34.17 GHz Bandpass Filter | MFBP-00101CH |
| Passive GaAs MMIC 32 - 39.3 GHz Bandpass Filter | MFBP-00102CH |
| Passive GaAs MMIC 44.1 - 51.2 GHz Bandpass Filter | MFBP-00103CH |
| Passive GaAs MMIC 2.2 - 5.5 GHz Bandpass Filter | MFBP-00112CH |
| Passive GaAs MMIC 8.5 - 10 GHz Bandpass Filter | MFBP-00113CH |
| Passive GaAs MMIC 10 - 13.5 GHz Bandpass Filter | MFBP-00114CH |
| Passive GaAs MMIC 14 - 17.7 GHz Bandpass Filter | MFBP-00115CH |
| Passive GaAs MMIC 1.4 - 2.1 GHz Bandpass Filter | MFBP-00116CH |
| Passive GaAs MMIC 2.5 - 3.8 GHz Bandpass Filter | MFBP-00117CH |
| Passive GaAs MMIC 25.7 - 38.5 GHz Bandpass Filter | MFBP-00118CH |
| Passive GaAs MMIC 32.5 - 43.1 GHz Bandpass Filter | MFBP-00119CH |
