New 16-26 GHz Double-Balanced Fundamental Mixer Offers High Isolation


Custom MMIC, a developer of performance-driven monolithic microwave integrated circuits (MMICs) is pleased to announce the release of the CMD179, a fundamental mixer in die form.

The CMD179 is a general purpose, double-balanced GaAs mixer that can be used for up- and down-converting applications between 16 and 26 GHz. The mixer, which offers conversion loss of 7 dB, an LO to RF isolation of greater than 40 dB, an IF bandwidth of 8 GHz, and an input IP3 of +18 dBm, is ideally suited for hybrid assemblies given its small die size of 0.9 mm^2.

A key advantage of the CMD179 is the very high suppression of spurious products due to the ultra small, optimized balun structures. The mixer can operate with an LO drive level as low as +9 dBm, though the linearity and spur suppression will improve with increased drive. Finally, two CMD179s can easily be configured as an image reject mixer or single sideband modulator with external hybrids and power splitters.

Ideal applications for the CMD179 are point-to-point and point-to-multipoint radios, test equipment, sensors, and military end-use.

About Custom MMIC
Custom MMIC represents a new way of thinking about MMICs. Driven by customer challenges, the company offers both hands-on design through testing services, and a growing library of system-ready designs. They are experienced in GaAs, GaN, SiC, InP, and InGaP HBT and have established relationships with the leading foundries in these technologies. They specialize in RF through millimeter-wave circuits for satellite communications, radar systems, cellular infrastructure, consumer electronics, VSAT, and point-to-point radio systems. For more information, visit
