New Custom MMIC SPDT Non-Reflective Switch Offers Positive Gain Slope

Custom MMIC, a developer of performance-driven monolithic microwave integrated circuits (MMICs), is pleased to announce the addition of the CMD195, a new DC-20 GHz non-reflective SPDT switch, to their growing line of control products.

The CMD195 operates across the DC to 20 GHz bandwidth with an insertion loss of 2.5 dB that reduces to 2 dB as the frequency increases. The terminated switch has an isolation of greater than 40 dB, port return losses less than -15 dB, an input 1 dB compression point of +25 dBm, and a switching speed of 1.8 nS. Switching operation is controlled by a pair of complementary logic signals at 0/-5 V.

Ideal applications for the CMD195 are microwave radio and VSAT, telecom infrastructure, test instrumentation, and military end-use. The positive gain slope of the CMD195 versus frequency allows for natural gain equalization when multiple switches are cascaded together.

To download the full datasheet for the CMD195 SPDT Non-Reflective Switch, visit the Custom MMIC Product Library.

About Custom MMIC
Custom MMIC represents a new way of thinking about MMICs. Driven by customer challenges, the company offers both hands-on design through testing services, and a growing library of system-ready designs. They are experienced in GaAs, GaN, SiC, InP, and InGaP HBT and have established relationships with the leading foundries in these technologies. They specialize in RF through millimeter-wave circuits for satellite communications, radar systems, cellular infrastructure, consumer electronics, VSAT, and point-to-point radio systems. For more information, visit www.CustomMMIC.com.
