Mtron Crosses To CTS Products

Mtron continues to support industry standard 9x14mm and 5x7mm packaged frequency control products. These packages are very popular among many customers and Mtron is committed to supporting these products. CTS has announced the End of Life for products in these packages and in many cases,  Mtron will have the direct cross. A partial listing of direct crosses includes the following:

CTS Series |  Mtron Series

M5623  M1 Series

T5323  M2 Series

T5623  M1 Series

T5724  M1 Series

VF540  M7S/M8S Series

VF561EL  M220x Series

VF596EL  M320x Series

VFAC570  M7S/M8S Series

VFH2224  M2 Series

VFVX321  M310x Series

VFXO321  M210x Series & M2058 Series

VFH2221  M630X Series

T5321  M630X Series

T5324  M2 Series

If you need a product crossed that is not on this list, please reach out to Mtron. Mtron supports multiple stability and output options with a wide operating temperature range up to -55°C to 125°C. Both RoHS and non-RoHS options are available and MIL-PRF55310 Level B screening is available when required.

Mtron offers a broad line of precision crystal resonators, oscillators, filters, and Integrated Microwave Assembly solutions.  Mtron is an ISO 9001:2015 and AS9100 Rev. D certified organization.

Features:
9x14mm and 5x7mm packages
Operating voltage 5V, 3.3V or 2.5V
Frequency range up to 1.4GHz
Operating temperature range up to -55 °C to +125 °C
MIL-PRF-55310 Screening

Applications:
Communication and Navigation
Avionics and Aerospace
Test and Measurement
Industrial
