News | September 19, 2016

Anritsu Introduces Comprehensive Front Haul Solution That Conducts Fast, Accurate RF And Fiber Tests

Anristu

Single Instrument Combines Industry Leading Fiber and RF Measurement Capability for More Efficient Method of Ensuring Proper Deployment, Operation of High-speed LTE Networks

Anritsu Company has leveraged its industry leading fiber and RF testing capability to develop the industry’s fastest comprehensive front haul test solution that more efficiently ensures the proper installation and operation of high-speed LTE networks. With the new CPRI RF module installed in the Anritsu Network Master Pro MT1000A, wireless carrier engineers and technicians responsible for optical fiber testing, and solving interference and PIM issues have a single handheld solution for accurate and efficient LTE CPRI testing and verification of the latest generation of tower mounted radios (Remote Radio Heads, RRH).

The Network Master Pro MT1000A with CPRI RF module has a fast sweep speed, allowing it to conduct measurements up to 10x faster than comparable handheld test solutions. The result is that users can capture all interfering signals, including intermittent or “bursty” interferers missed by current alternatives. Incorporating a Spectrum/Spectrogram Tune & Zoom feature, the Network Master Pro MT1000A with CPRI RF module allows users to zoom in on an area of interest to provide more detailed information for better identification of an interfering signal’s origin.

Support for all leading RRH radios is provided by the new CPRI RF module. It allows the Network Master Pro MT1000A to conduct RF-based LTE measurements over a fiber optic CPRI link at ground level, eliminating the time-consuming and costly process of climbing a tower. Designed with two SFP ports, the RF module allows CPRI Spectrum, CPRI Spectrogram, SFP Data, and CPRI Layer 2 Alarms and Optical Power measurements to be made.

The module features pre-configured NEM (network element manufacturers) setups to simplify what has been one of the most difficult aspects to conducting RF measurements over CPRI. The result is reduced test set-up time and a lower possibility of errors for greater measurement confidence.

Anritsu is offering a single-mode optical tap accessory and a combination single-mode/multi-mode 50 µm optical tap accessory as part of the solution. An SFP matching the connected CPRI link rate and optical cables are offered, as well.

The CPRI RF measurement capability complements the Network Master Pro MT1000A fiber testing ability. Compact, battery-powered and easy-to-use, the MT1000A provides everything needed to install and maintain communication networks in a rugged, field portable package. The mobile front haul fiber test functions of the MT1000A support comprehensive testing and analysis of CPRI and OBSAI technologies. The MT1000A can be configured as a complete solution with support for OTDR and VIP (Visual Inspection Probe), to test the complete CPRI infrastructure. The MT1000A supports CPRI interface rate Option 1 (614.4 Mbit/s) to Option 8 (10.1376 Gbit/s) to test current and future CPRI interfaces. It can identify problems in the mobile front haul rapidly, solve issues quickly, reduce system downtime and customer churn, and cut operating costs for mobile operators.

The lightweight MT1000A supports transport testing from 1.5 Mbps to 10 Gbps. An easy-to-use GUI and clear summaries simplify collecting and interpreting data, allowing users of any skill level to operate the instrument. High resolution and dynamic range ensure quick and thorough fiber evaluation, while intelligent analysis software identifies problem splices, connectors and macrobends.

About Anritsu
Anritsu Corporation has been a provider of innovative communications solutions for more than 120 years. The company's test and measurement solutions include wireless, optical, microwave/RF and digital instruments, operations support systems and solutions that can be used during R&D, manufacturing, installation, and maintenance. Anritsu also provides precision microwave/RF components, optical devices, and high-speed devices for design into communication products and systems. With the addition of OSS monitoring solutions it has expanded its offering to provide complete solutions for existing and next-generation wireline and wireless communication systems and service providers. Anritsu sells in over 90 countries worldwide with approximately 4,000 employees. For more information, visit www.anritsu.com.

Source: Anritsu Corporation
