PASSIVE COMPONENTS APPLICATION NOTES AND WHITE PAPERS

  • A Novel RF Coupler For SMART Utility Meter Remote Antenna Applications

    In response to climate change nations across the globe have recognized the need for reducing their carbon emissions, and energy consumption. By Norman Smith, Gopinath Gampala & CJ Reddy

  • Thermal Power Testing Methodology for Chip, Flange, and PCB-Mounted Resistors

    Resistors can be used to dissipate excess power, act as a system’s safety mechanism, provide a matching device, and more. Resistors convert electrical energy into heat energy through the use of a resistive element. They’re usually mounted to a heatsink, a flange, or directly on a PCB.

  • Power Handling Considerations for SMD Terminations, Attenuators, and Resistors

    Power ratings for Anaren’s SMD Terminations, Attenuators, and Resistors are based off of the temperature at the solder interface where the solder is in contact with the SMD components. This application note describes the power rating of high power surface mount resistive products, as well as techniques for maximizing power handling performance of these products.

  • Recommended Soldering Techniques for SMD, Chip, Flangeless, and Flanged Resistors

    This application note provides recommendations for attached Anaren’s SMD, chip, flangeless, and flanged resistive products. A good solder joint can be critical in achieving a chip’s maximum performance. Mounting considerations for each different type are included with accompanying figures for visual aids. All Anaren resistives have a matte tin outside finish to achieve good solderability and RoHS compliance.

More Passive Components Case Studies and White Papers

PASSIVE COMPONENTS PRODUCTS

5,6 Way Lumped Element Power Dividers and Combiners: PL5 and PL6 Series

5,6 Way Lumped Element Power Dividers and Combiners: PL5 and PL6 Series

The PL5 and PL6 series is a family and 5 and 6 way lumped element power dividers and combiners covering the 1-1000 MHz frequency range. They feature uniform amplitude and phase balance, low insertion loss, high isolation, low VSWR, and high reliability.

2-Way Octave Power Divider: DMS208

2-Way Octave Power Divider: DMS208

TRM Microwave’s DMS208 is a 2-way power divider that covers the 4-8 GHz frequency range. It features high isolation (23 dB min), excellent phase (2 Degrees max) and amplitude (0.2 dB max) balance, 30 Watts (max) input power, and 0.4 dB (max) insertion loss. SMA connectors come standard, though N, BNC, and TNC are optional. For mechanical specifications, download the datasheet.

High Power 8-Way Combiner: D5829

High Power 8-Way Combiner: D5829

This high power, 8-way combiner covers the 20-500 MHz frequency range and has an output power of 400 W CW. It can also be used to achieve 50 Watts/input in non-coherent combining applications. It has an insertion loss of 0.75 dB (max), 1.40:1 (max) VSWR, 20 dB (min) isolation, a +5o (max) phase balance, and a 0.3 dB (max) amplitude balance. For more information, download the datasheet.

2-40 GHz Directional Couplers: 102040010/K

2-40 GHz Directional Couplers: 102040010/K

These compact and lightweight directional couplers cover the 2.0 to 40.0 GHz frequency range and offer 10 dB nominal coupling. They’re ideal for signal monitoring and measurement, military and EMC testing environments, antenna beam forming, cable distributed systems, and other broadband electronic warfare (EW) and commercial wireless systems.

3dB Hybrid Couplers: TEMline™ Series

3dB Hybrid Couplers: TEMline™ Series

API Technologies’ TEMlineTM series of 3dB hybrid couplers have an average power rating of 1000W and are normalized at 1GHz. They also feature 1 dB maximum unbalance and 90 degree phase differential between outputs. They’ve been designed to meet MIL-E-5400 Class 3 and are screenable to MIL-P-23971, making them an ideal solution for telecommunications and radar applications.

High-Performance and Ultra-Broadband Directional Couplers

High-Performance and Ultra-Broadband Directional Couplers

KRYTAR’s 152610, 152616, and 152620 directional couplers cover the 0.5 GHz to 26.5 GHz frequency range. They’re ideal for applications with space constraints because of their small size. They’d be well-suited for use in signal monitoring and measurement, EMC testing, antenna beam forming, and cable distributed systems.

Multiplexer for Radar, EW, and ELINT: NF29525

Multiplexer for Radar, EW, and ELINT: NF29525

The NF29525 is a multiplexer with an integrated low noise amplifier. It covers the 2 to 18 GHz frequency range and has been specifically designed for agile receiver front ends and directional finding systems.

Custom EMI Filters

Custom EMI Filters

EMI Filters are used to prevent electromagnetic interference in avionics and aircraft systems, as well as military shipboard/vehicle electronics, and in military communication systems. Electromagnetic interference can cause a complete loss of data in communications systems, or a simple decline in data quality.

More Passive Components Products
