Gallium Nitride Broadband RF Power Amplifier: SSPA 0.020-0.520-125

Gallium Nitride Broadband RF Power Amplifier: SSPA 0.020-0.520-125

Aethercomm Model Number SSPA 0.020-0.520-125 is a high power, broadband, Gallium Nitride (GaN) RF amplifier that operates from 20 MHz to 520 MHz. This PA is ideal for broadband military platforms as well as commercial applications because it is robust and offers high power over a multi-octave bandwidth. This amplifier was designed for broad band jamming and communication systems platforms.
Next Generation 1 kW Broadband Amplifier Family

Next Generation 1 kW Broadband Amplifier Family

Empower RF’s family of next generation 1 kW broadband amplifiers are compact and LDMOS based. Three different models are available. Model 2126 operates in the 20 to 500 MHz frequency range. Model 2066 covers 500 to 1000 MHz. Model 2162 operates in the 20 to 1000 MHz frequency range.

High-Power Broadband Gallium Nitride RF Amplifier: SSPA 0.020-6.000-35

High-Power Broadband Gallium Nitride RF Amplifier: SSPA 0.020-6.000-35

Aethercomm Model Number SSPA 0.020-6.000-35 is a high power, super broadband, Gallium Nitride RF amplifier that operates from 20 MHz to 6000 MHz. This PA is ideal for broadband military platforms as well as commercial applications because it is robust and offers high power over a multi-decade bandwidth with decent power added efficiency. This is an industry first for bandwidth, power and efficiency in a package like this. This amplifier operates from a base plate temperature -40°C to +75°C for maximum performance. It is packaged in a modular housing that is 7.65(w)” by 2.5(l)” by 1.27(h)”. This amplifier has a typical P3dB between 35 to 50 watts at room temperature.
10,000 Watt RF Power Amplifier: 10000A225

10,000 Watt RF Power Amplifier: 10000A225

This RF power amplifier offers 10,000 watt CW and covers the 10 kHz to 225 MHz frequency range. It’s ideal for applications that involve RF susceptibility testing, antenna and component testing, communications, watt meter calibration, plasma generation, particle accelerators, and for use as a driver for high power amplifiers.

Model NP-507: Broadband Linear RF Amplifier

Model NP-507: Broadband Linear RF Amplifier

Designed for linear application in the 10 to 1000 MHz range. This amplifier utilizes RF Power MOSFET devices that provide high gain, wide dynamic range and an excellent 3rd order intercept point. Suggested applications: multi-carrier, pulse, AM & FM modulation.
Broadband High Power RF Amplifier: 20 MHz to 1000 MHz

Broadband High Power RF Amplifier: 20 MHz to 1000 MHz

Ophir RF’s 6010 broadband high power RF amplifier is ideal for NMR applications. It operates in the 20 to 1000 MHz frequency range and has a saturated output power of 125 Watts (min). It also has +52 dB (min) small signal gain, 50dB (min) blanking, <5uS blanking speed, -20 dBc (typ) harmonics @90 Watts, >-60 dBc (typ) @90 Watts, and much more. Additional specifications can be found on the available datasheet.

500 Watts CW Solid-State Amplifier: 500W1000B

500 Watts CW Solid-State Amplifier: 500W1000B

This solid-state amplifier covers the 80 MHz to 1000 MHz frequency range and uses push-pull circuitry in its higher power stages in order to lower distortion and improve stability. It’s particularly well suited for applications that require an amplifier with high gain and instantaneous bandwidth.

Broadband Bench Top Amplifiers 0.1 - 40.0 GHz

Broadband Bench Top Amplifiers 0.1 - 40.0 GHz

Microsemi RFIS has designed a range of bench top amplifiers that operate in the 0.1 – 40.0 GHz frequency range, and are ideal for production test and laboratory applications. This page covers the AML0126P3002-BT.
