WCS/MMDS Air Cavity Diplexer

WCS/MMDS Air Cavity Diplexer

This diplexer uses TE Mode waveguide puck resonators to achieve narrowband filters of less than 0.25% bandwidth yet still provide a pass band loss on the order of < 1.5 dB. In addition to the low loss provided by the high Q ceramic resonators, cross coupling is used to achieve very deep rejection of 75 dBc at a 4:1 shape factor. This device also incorporates a sampling coupler and is available in both diplexer and double band pass configurations in frequency ranges of 2250 MHz to 2800 MHz...

260/915 MHz Diplexer - Lumped Component Diplexer

260/915 MHz Diplexer - Lumped Component Diplexer

Features: SMA Connectors, 1.5:1 VSWR from 20 MHz to 1200MHz
FTTP Cable Diplexer

FTTP Cable Diplexer

The FTTP Cable Diplexer uses LC high pass / low pass construction along with delay equalization to provide a clean method of inserting and removing broadband digital service from cable systems. The delay equalizer assists in providing a low distortion path for the digital signal. High volume, inexpensive construction is achieved by casting the housing with connectors molded into a single assembly. Further price reduction is achieved by an internal design which lends itself to pick and place construction...
Filters, Diplexers, And Multiplexers

Filters, Diplexers, And Multiplexers

Continental Microwave offers a comprehensive line of filters, diplexers and multiplexers from 400 MHz to 50 GHz. A broad range of custom waveguide and coaxial designs are available offering extreme temperature stability and low insertion loss for data links, military satellite communications, missiles and radar applications
High-Power And Broadband Matched Band-Pass/Band-Stop Diplexers

High-Power And Broadband Matched Band-Pass/Band-Stop Diplexers

Designed for testing applications, K&L Microwave’s band-pass/band-stop diplexers feature broadband matching at the common port, low insertion loss, and high isolation. These diplexers are also used in band combining/splitting applications, up/down converters, and in multiplexer modules...
LC Bandpass Filters & Duplexers/Diplexers

LC Bandpass Filters & Duplexers/Diplexers

Anatech Electronics manufactures standard and custom LC Bandpass filters and Duplexers/Diplexers from 0.1 MHz – 20 GHz.
Low Pass/High Pass Diplexer: DPX-0508

Low Pass/High Pass Diplexer: DPX-0508

This broadband low pass/high pass diplexer is capable of multiplexing low frequency (DC-5 GHz) and high frequency (8-18 GHz) signals. It features broadband performance, a lightweight and compact design, low insertion loss, and high isolation between low pass and high pass ports.

Multilayer Diplexer (DPX205950DT-9008A1)

Multilayer Diplexer (DPX205950DT-9008A1)by Digi-Key.
