News | December 19, 2013

Abracon Introduces Precision Wide Operating Temperature TCXOs In 5.0x7.0mm Footprint

AST3TQ Series

Abracon Corporation introduces its AST3TQ series of precision Temperature Compensated Crystal Oscillators.

Rancho Santa Margarita, CA (PRWEB) - A globally preferred, leading supplier of frequency control and magnetic components, Abracon Corporation introduces its AST3TQ series of precision, -55ºC to +95ºC, Temperature Compensated Crystal Oscillators.

“The AST3TQ series of Temperature Compensated Crystal Oscillators is available from 10MHz to 40MHz carrier frequencies with LVCMOS output, offering ±500 ppb frequency stability over -55ºC to +95ºC,” explains Syed Raza, Director of Engineering at Abracon Corporation.

“These devices comply with Stratum-III stability of < ±4.60ppm all inclusive error over a 20-year product life. Temperature stability options include ±100ppb over -40ºC to +85ºC, ±280ppb over -50ºC to +90ºC and ±500ppb over -55ºC to +95ºC operating temperature ranges. With maximum current drain of 10mA @ 40MHz, these devices offer OCXO level accuracy over a wide operating temperature range, with minimal power consumption,” continues Raza.

Potential applications for these solutions include: COTS Military Radios & other Communication Hardware, WiMax, LTE, BTS, CATV, LAN, LMDS, GPS Tracking with hold-over accuracy, Test & Measurement Equipment, and Point-to-Point communication networks.

Key features include:
• Standard available frequencies: 10.00, 12.80, 19.20, 20.00, 25.00, 26.00, 30.72, 38.40 and 40.00MHz
• Standard LVCMOS output
• Frequency stabilities to include: ±100ppb over -40ºC to +85ºC, ±280ppb over –50ºC to +90ºC, and ±500ppb over -55ºC to +95ºC operating temperature ranges
• Excellent Phase Noise, Harmonics and Spurious content
• Typical RMS jitter of 400fs @ 40MHz carrier and 1.0ps @ 10MHz carrier over 12kHz to 20MHz BW

The AST3TQ series will be available through Abracon's Global Distribution partners by February 2014.

Abracon Link:
http://www.abracon.com/Oscillators/AST3TQ.pdf

For technical assistance with this product, please contact Abracon Corporation at tech-support(at)abracon(dot)com.

Abracon Corporation was established in 1992 with the vision of becoming a top tier global manufacturer of Frequency Control, Signal Conditioning, Clock Distribution, Radio Frequency and Magnetic Components with local design and technical support. Abracon provides its customers with high quality products, competitive pricing, timely delivery, reliable engineering and technical support, plus production flexibility worldwide.

SOURCE: PRWeb

View original release here: http://www.prweb.com/releases/2013/Abracon/prweb11434659.htm
